Application: Other
Video: Video link
Application: This Out-arc Grinding Machine for Motorcycle Brake Shoe is used to out-arc grinding for motorcycle brake shoe.
Performance Characteristics:
Adopting pneumatic clamping and feeding,PLC programming control, the rotating speed of main spindle can be adjustable. Diamond grinding tool,Having the features of setup clamping conveniently, Low labor intensity, Grinding texture smoothly and High precision etc.
Technical Data:
Grinding motor: 3kw 2880 r / min
Feed motor: 0.55kw 1390 r / min
Rotating speed of main spindle: adjustable
Grinding Range: Ф 100-280mm
Width of brake lining : 10mm-40mm
Production Efficiency: 6-8 seconds/set (Or 60*r/min)
Diameter of Grinding Wheel: Ф200×40mm
Total weight: About 500 kg
